Made in Finland
Designed in Finland
Nokian Tyres Logger King LS-2 is a new skidder tire made for the hardest conditions and the biggest machinery. It has the ruggedness to offer a long, trouble free service life as well as some clever features to speed up your daily work. Nokian Tyres Logger King LS-2 works with or without tracks. The tire features high groove bottom on the shoulder area. This gives more support to track paws and protects the tyre from damage.
When working on distant sites, you don’t want any surprises. Nokian Tyres Logger King LS-2 tire is designed for a long, trouble-free service life in heavy skidder use. Its ultra-durable, high-strength multi-layer textile carcass with wide steel breakers offers an excellent puncture resistance – also in the shoulder area.
Nokian Tyres Logger King LS-2 tire features an aggressive tread design with excellent self-cleaning properties. This ensures good grip even on mud and wet surfaces. Its special rubber compound in the bead area minimizes rim slip and unique single wire bead construction makes on-site assembly easier.
Nokian Tyres Logger King LS-2 is also available in Extreme version for the heaviest machinery and hardest conditions. Offering a load capacity up to 12 250 kg (27 000 lbs), the Extreme version is the ultimate tire for professional skidding. The Extreme version is available in sizes 30.5L-32 and 35.5L-32.
| LI / SS | Recommended rim | Permitted rims | Tire width | Tire diameter | Static loaded radius | Tread depth |
|---|---|---|---|---|---|---|
| 165A6 (161A8) | DW25B | - | 720 mm28.4 in | 1647 mm64.8 in | 754 mm29.7 in | 58 mm73/32 in |
| LI / SS | 165A6 (161A8) |
|---|---|
| Recommended rim | DW25B |
| Permitted rims | - |
| Tire width | 720 mm28.4 in |
| Tire diameter | 1647 mm64.8 in |
| Static loaded radius | 754 mm29.7 in |
| Tread depth | 58 mm73/32 in |
| Rolling circumference | Speed radius index | Max inflation pressure | PR |
|---|---|---|---|
| 4945 mm194.7 in | - | 280 kPa41 psi | 20 |
| Rolling circumference | 4945 mm194.7 in |
|---|---|
| Speed radius index | - |
| Max inflation pressure | 280 kPa41 psi |
| PR | 20 |
| Product code |
|---|
| T445615 |
| Product code | T445615 |
|---|
| LI / SS | Recommended rim | Permitted rims | Tire width | Tire diameter | Static loaded radius | Tread depth |
|---|---|---|---|---|---|---|
| 160A6 (156A8) | DW20B | - | 604 mm23.8 in | 1623 mm63.9 in | 749 mm29.5 in | 54 mm68/32 in |
| LI / SS | 160A6 (156A8) |
|---|---|
| Recommended rim | DW20B |
| Permitted rims | - |
| Tire width | 604 mm23.8 in |
| Tire diameter | 1623 mm63.9 in |
| Static loaded radius | 749 mm29.5 in |
| Tread depth | 54 mm68/32 in |
| Rolling circumference | Speed radius index | Max inflation pressure | PR |
|---|---|---|---|
| 4882 mm192.2 in | - | 280 kPa41 psi | 16 |
| Rolling circumference | 4882 mm192.2 in |
|---|---|
| Speed radius index | - |
| Max inflation pressure | 280 kPa41 psi |
| PR | 16 |
| Product code |
|---|
| T445616 |
| Product code | T445616 |
|---|
| LI / SS | Recommended rim | Permitted rims | Tire width | Tire diameter | Static loaded radius | Tread depth |
|---|---|---|---|---|---|---|
| 169A6 (167A8) | DH21 | - | 637 mm25.1 in | 1829 mm72 in | 846 mm33.3 in | 58 mm73/32 in |
| LI / SS | 169A6 (167A8) |
|---|---|
| Recommended rim | DH21 |
| Permitted rims | - |
| Tire width | 637 mm25.1 in |
| Tire diameter | 1829 mm72 in |
| Static loaded radius | 846 mm33.3 in |
| Tread depth | 58 mm73/32 in |
| Rolling circumference | Speed radius index | Max inflation pressure | PR |
|---|---|---|---|
| 5517 mm217.2 in | - | 310 kPa45 psi | 20 |
| Rolling circumference | 5517 mm217.2 in |
|---|---|
| Speed radius index | - |
| Max inflation pressure | 310 kPa45 psi |
| PR | 20 |
| Product code |
|---|
| T445614 |
| Product code | T445614 |
|---|
| LI / SS | Recommended rim | Permitted rims | Tire width | Tire diameter | Static loaded radius | Tread depth |
|---|---|---|---|---|---|---|
| 170A6 (167A8) | DH27 | - | 773 mm30.4 in | 1843 mm72.6 in | 853 mm33.6 in | 67 mm84/32 in |
| LI / SS | 170A6 (167A8) |
|---|---|
| Recommended rim | DH27 |
| Permitted rims | - |
| Tire width | 773 mm30.4 in |
| Tire diameter | 1843 mm72.6 in |
| Static loaded radius | 853 mm33.6 in |
| Tread depth | 67 mm84/32 in |
| Rolling circumference | Speed radius index | Max inflation pressure | PR |
|---|---|---|---|
| 5542 mm218.2 in | - | 240 kPa35 psi | 20 |
| Rolling circumference | 5542 mm218.2 in |
|---|---|
| Speed radius index | - |
| Max inflation pressure | 240 kPa35 psi |
| PR | 20 |
| Product code |
|---|
| T445621 |
| Product code | T445621 |
|---|
